- Place of Origin: China
- Brand Name: shandonglongtaiguoxiang
- Model Number: TQLZ
Materials of Design ,
1. The screen body is welded by SPCC (high quality cold-rolled steel plate with standard thickness 3mm).
2. The screen frame is made of steel, with at least ten years’ service life.
3. The screen deck is made of finest manganese plate and stainless steel screen mesh which can be customized.
Treatment of Exterior ,
1. All the frames have been chemically processed: acid pickling, phosphating, and anti-rust treatment.
2. Anti-corrosive primer has been sprayed firstly, then finishing coating adopts famous high quality fade-proof stoving varnish.
3. The surface is glossy, firm and not easy to fade or drop, with strong scratch-proof ability.
- Place of Origin: China
- Brand Name: shandonglongtaiguoxiang
- Model Number: TQLZ
Technical Parameters ,
| Types | Output (t/h) | Power （ kw ） | Amplitude (mm) | Screen gradient (∠) | Screen size (W*L) | Dimension (L*W*H) |
| TQLZ100*200 | 15~20 | 2.99 | 4.5-5.5 | 8-12 | 1000*2000 | 3450*1850*1862 |
| TQLZ150*200 | 30~40 | 5.25 | 4.5-5.5 | 8-12 | 1500*2000 | 3500*2500*1962 |
| TQLZ180*200 | 50~60 | 5.25 | 4.5-5.5 | 8-12 | 1800*2000 | 3500*2800*1962 |
| TQLZ200*200 | 50~80 | 7.35 | 4.5-5.5 | 8-12 | 2000*2000 | 3500*3000*1875 |
| TQLZ150*270-3C | 50~80 | 8.15 | 4.5-5.5 | 15 | 1500*2700 | 4100*2500*2580 |
